Slide Glass

Sliding system for glass structure installation without thermal insulation, characterized by minimal visibility of the edges of aluminum profiles.


              The Slide Glass system offers a solution for a profile-free labyrinth joint (without sealing) or a joint between movable door leaves using a narrow brush profile.


               Possibility of using 3-, 4- and 5-track guides


               Infill: 10 mm thick tempered glass


               Concealed drainage is possible in the system through lower subframe profiles


               The system is equipped with dedicated hardware:
                - adjustable or non-adjustable trolleys
                - glass-fixed handle pull
                - and special hook locks


               It can be closed using the built-in catch or the side closure with a lock.


               The rails for moving the door leaves can be made of aluminum or stainless steel (the rails      can be independent, mounted in the travel tracks).


                System-based solutions provide for the possibility of compensating deflections from components located above the sliding body.


                A  wide range of colors is available from RAL-palette, texture colors, wood look effect colors and two tone colors.


System application:

               Installation of vertical walls in pergolas, terraces, etc.

               Sliding glass doors

Inspiration
